MAN TGM & MAN TGL – Specifications

Side view of the MAN TGM and MAN TGL.
The MAN TGM and MAN TGL:
Configurator

AT A GLANCE

  • Chassis overview 
    All important features of the chassis available for MAN TGM and MAN TGL and their intended uses are listed here. 
  • All motorisation variants and cabs
    Find out all you need to know to find the right MAN TGM or MAN TGL for your needs.
  • Overview of the MAN media systems
    The assistance and entertainment systems of the MAN TGM and MAN TGL: ensure the driver is comfortable and safe.

YOUR SPECIFICATIONS, OUR SOLUTION 

The MAN TGM and MAN TGL is an ideal partner for various transport tasks. With a high payload capacity and powerful yet economical engines, it offers optimum efficiency and reliability. Your choice from the plethora of model options, such as chassis, cabs and various media systems, can be adapted to your specific needs and you can benefit from the tried-and-tested quality and flexibility of MAN.

Whether you need a tipper truck or wheel loader, have special requirements for the cab or want to check how fast your driver is completing their tasks, these vehicles boast efficient and modern technology, such as the converter automatic gearbox MAN PowerMatic as well as environmentally friendly engines that meet current emission standards.

  Chassis Tipper
4x2 TGM/TGL TGM/TGL
4x4 TGM TGM
6x2- TGM _
6x2 _ _
6x4 TGM TGM
6x4- _ _
6x6 _ _
8x2- _ _
8x4 _ _
8x4/ 8x4- _ _
8x6
8x8 		_ _
Engine series Cylinder, design Displacement [Liter] Performance [kW (PS)] Euro 6 emission standard For vehicle series
D0836 6 in-line 6.9 235 (320)
213 (290)
184 (250) 		✔ TGM
TGM
TGM/TGL
D0834 4 in-line 4.6 162 (220)
140 (190)
118 (160) 		✔ TGL
TGL
TGL
  CC cab:
The compact (slim, short, medium high) 		DN cab:
The double cabin
Main dimensions
External length 1,620 mm 2,790 mm
External width 2,240 mm 2,240 mm
Interior length 1,550 mm 2,650 mm
Interior width 2,070 mm 2,070 mm
Engine tunnel height 260/140 mm 1) 260 mm
Standing height on the engine tunnel 1,280 mm 1,385 mm

Seats
Quantity 2 (optionally 3) items 6 (optionally 7) items
Standing height in front of the co-driver’s seat 1,585 mm 1,645/1,620 mm 2)

Volume
Roof storage compartments 27 l 41 l
Roof luggage rack _ _
Rear left storage box _ _
Rear right storage box _ _
Central storage space below bed 3) _ _

Suitable application
Standard long-haul transport Qualified Qualified
Long-distance transport payload Qualified Qualified
Traction (construction site) Very good Very good
Distribution transport Very good Qualified
Municipal Very good Very good
  1. Engine tunnel height 260 mm for TGL with D0836, 140 mm for TGL with D0834
  2. Standing height in front of the co-driver’s seat 1,645 mm, standing height in front of the second seat row 1,620 mm
  3. Maximum values, depending on the configuration
  MAN media system Navigation Professional 12.3 inches MAN media system Navigation Advanced 7 inches MAN media system Advanced 7 inches MAN media system Medium 7 inches MAN media system 7 inches MAN radio SD card 7 inches
Equipment details
Screen diagonal 12.3" 7" 7" 7" 7" 7"
Resolution 1,920 x 720 pixels 800 x 480 pixels 800 x 480 pixels 800 x 480 pixels 800 x 480 pixels 800 x 480 pixels
Can be combined with MAN SmartSelect ✔ ✔ ✔ _ _ _

Radio functions
AM/FM tuner ✔ ✔ ✔ ✔ ✔ ✔
Sound tuning ✔ ✔ ✔ ✔ ✔ ✔
DAB/DAB+ ✔ ✔ ✔ ✔ ✔ _
Message centre ✔ ✔ ✔ _ _ _

Telephone services
Basic hands free function _ _ ✔ ✔ ✔ _
Comfort hands free function for two mobile phones ✔ ✔ _ _ _ _

Traffic functions
Truck navigation ✔ ✔ _ _ _ _
Various options for map update ✔ ✔ _ _ _ _
Online traffic for navigation function ✔ ✔ _ _ _ _
Traffic sign detection (based on map data only) ✔ ✔ _ _ _ _
Traffic sign detection (based on camera and map data) ✔ ✔ ✔ ✔ _ _

Entertainment functions
Bluetooth ® music streaming ✔ ✔ ✔ ✔ ✔ _
Smartphone integration ✔ ✔ ✔ ✔ _ _
SD card reader ✔ ✔ ✔ ✔ ✔ ✔

Feature enhancements
Reversing Motion System (rear area monitoring) ✔ ✔ ✔ ✔ _ _
Preparation for camera _ _ ✔ ✔ _ _
Preparation for camera, coupled with reverse gear _ _ ✔ ✔ _ _
Preparation for two cameras ✔ ✔ _ _ _ _
Preparation for 2 cameras, one camera coupled with reverse gear ✔ ✔ _ _ _ _
Option to integrate MAN Apps in the vehicle ✔ ✔ ✔ _ _ _

Connections/interfaces
Connection option for external audio signal sources in the centre console ✔ ✔ ✔ ✔ ✔ _
AUX-in input via 3.5 mm jack socket ✔ ✔ ✔ ✔ ✔ _
USB interface (type C) with charging function ✔ ✔ ✔ ✔ ✔ _
